IKW40N65H5 – 650V, 40A High-Speed IGBT with Soft Switching

Description

Technical specifications:

• IGBT type: HighSpeed 5 Trench-Field Stop IGBT
• Collector-emitter voltage (Vces): 650V
• Collector current (Ic): 40A (continuous)
• Saturation voltage (VCE(sat)): 1.55V (typical)
• Switching frequency: Up to 100 kHz
• Gate charge (Qg): 200nC
• Diode recovery time: Fast and soft recovery
• Package: TO-247
• Operating temperature range: -55°C to +150°C
• Applications: Solar inverters, UPS, induction heating, welding equipment, SMPS

Product features:

• High breakdown voltage: 650V for robust power handling.
• Low VCE(sat): Reduces conduction losses and improves efficiency.
• High-speed switching: Optimized for soft switching and reduced switching loss.
• Tailored for resonant applications: Excellent for zero-voltage switching (ZVS) and zero-current switching (ZCS).
• Rugged TO-247 package: Ensures good thermal performance and ease of integration.
• RoHS compliant: Lead-free and environmentally friendly.
