DMN3404L-7 – N-Channel MOSFET (20V, 4.2A, Low RDS(on))

Description

Technical Specifications:

• Type: N-Channel MOSFET
• Drain-Source Voltage (VDS): 20V
• Continuous Drain Current (ID): 4.2A
• RDS(on): 0.045Ω @ VGS = 4.5V
• Gate Threshold Voltage (VGS(th)): 0.8V (typical)
• Package Type: SOT-23 (Small Outline Transistor)
• Operating Temperature Range: -55°C to +150°C
• Applications: Power management, DC-DC converters, load switching, motor control, and battery-powered devices.

Product Features:

• N-Channel MOSFET: Optimized for low-voltage switching applications.
• Low On-Resistance (RDS(on)): 0.045Ω for minimal power loss and high efficiency.
• High Current Capability: Supports up to 4.2A continuous current.
• Low Gate Threshold Voltage: 0.8V (typical) for low-voltage operation.
• Fast Switching Speed: Ideal for high-frequency applications.
• Compact SOT-23 Package: Small form factor for space-constrained designs.
• ESD Protection: Enhanced reliability against electrostatic discharge.
