CDNBS08-SLVU2.8-4 – 4-Channel Low Capacitance TVS Diode Array

The CDNBS08-SLVU2.8-4 is a low-capacitance transient voltage suppression (TVS) diode array designed to protect high-speed data lines from electrostatic discharge (ESD) and voltage transients. With a clamping voltage of 2.8V, this 4-channel diode array ensures superior protection for sensitive electronic components in USB, Ethernet, and high-speed data applications.

Product Brochure

Description

Technical Specifications:

  • Device Type: TVS Diode Array
  • Number of Channels: 4
  • Reverse Standoff Voltage (VRWM): 2.8V
  • Clamping Voltage: Low clamping for sensitive electronics
  • ESD Protection Level: ±30kV (Air & Contact) per IEC 61000-4-2
  • Capacitance: Low capacitance for minimal signal distortion
  • Mounting Type: Surface Mount (SMD) – SOT-23-6 Package
  • Operating Temperature: -55°C to +125°C
  • Applications: USB ports, Ethernet interfaces, HDMI, high-speed data lines, and industrial electronics

Product Features:

  • 4-Channel Protection: Safeguards multiple data lines from transient voltage surges
  • Low Capacitance: Ideal for high-speed data applications
  • ESD Protection: Meets IEC 61000-4-2 standards (±30kV Air, ±30kV Contact)
  • Low Clamping Voltage: 2.8V for minimal signal distortion
  • Fast Response Time: Instantly suppresses transient voltages
  • Surface Mount Package: Compact SOT-23-6 package for easy PCB integration
  • Operating Temperature Range: -55°C to +125°C for industrial and consumer applications
