Description

Technical Specifications:

• Type: TVS Diode Array
• Capacitance: Low capacitance of 0.5pF (typical) per line
• Protection Lines: Protects up to 4 data lines
• Peak Pulse Power (8/20 µs): 100W (typical)
• Clamping Voltage: Low clamping voltage for effective protection
• Package: DFN 1.0mm x 0.6mm x 0.5mm
• Operating Temperature Range: -40°C to +85°C
• Compliance: Meets IEC 61000-4-2 standards for ESD

Product Features:

• Low Capacitance: Ensures minimal signal distortion for high-speed data lines.
• Superior ESD Protection: Safeguards sensitive components against ESD events exceeding ±15kV (IEC 61000-4-2).
• Compact DFN Package: Space-saving design for modern electronics.
• Wide Operating Voltage Range: Supports up to 5V for data line protection.
• High Reliability: Robust protection for sensitive interfaces.
• RoHS Compliant: Environmentally friendly design, free from hazardous substances.
