ISL29038IROZ-T7 – Ambient and Infrared Light-to-Digital Sensor

Description

Technical specifications:

• Sensor type: Ambient and infrared light-to-digital converter
• Operating voltage: 2.25V to 3.63V
• Output format: 16-bit digital output
• Communication interface: I²C (up to 400kHz)
• Lux range: 0.015 lux to 64,000 lux
• IR sensitivity: Wide dynamic range for IR detection
• Package: 6-lead ODFN (2.0mm x 2.1mm)
• Operating temperature: -40°C to +85°C
• Applications: Mobile devices, tablets, displays, industrial lighting

Product features:

• Dual light sensing: Measures both ambient (visible) and infrared light
• 16-bit resolution: High precision light intensity output
• Adjustable range: Programmable lux range for flexible performance
• Infrared rejection: Superior rejection of IR light in ambient light sensing
• I²C interface: Supports standard 2-wire serial communication
• Low power consumption: Ideal for battery-operated devices
