IS62C256AL-45ULI-TR – 32K x 8 (256Kb) Low Power CMOS SRAM, 45ns, Industrial Temp, TSOP

Description

Technical specifications:

• Memory density: 256Kb (32K x 8)
• Access time: 45ns
• Operating voltage: 2.7V to 5.5V
• Standby current: 1µA (typical)
• Package: 28-pin TSOP I
• Temperature range: -40°C to +85°C (industrial)
• Applications: Embedded controllers, handheld devices, networking equipment, industrial systems

Product features:

• High-speed access: Fast 45ns access and cycle time for performance-critical systems
• Low power consumption: CMOS technology with standby and data retention modes
• Compact footprint: Available in space-saving 28-pin TSOP package
• Industrial temperature range: Operates from -40°C to +85°C
• Fully static operation: No clock or refresh required
• Easy interface: Compatible with standard TTL levels
