4816P-T02-103LF – 10kΩ Bussed Resistor Network

The 4816P-T02-103LF is a surface-mount resistor network from Bourns’ 4800P series, featuring fifteen 10kΩ resistors in a bussed configuration within a 16-pin SOIC package. Designed for efficient PCB space utilization, it offers precise resistance matching and is ideal for pull-up/pull-down applications and logic circuits.

Product Brochure

Description

Technical Specifications:

  • Resistance Value: 10kΩ per resistor
  • Tolerance: ±2%
  • Number of Resistors: 15
  • Number of Pins: 16
  • Power Rating per Resistor: 80mW
  • Maximum Operating Voltage: 50V
  • Temperature Coefficient: ±100ppm/°C
  • Operating Temperature Range: -55°C to +125°C
  • Package Type: 16-pin SOIC (Surface Mount)
  • Dimensions: 11.18mm (L) x 5.59mm (W)

Product Features:

  • Bussed Configuration: Fifteen resistors connected to a common bus, simplifying circuit design.
  • Compact SOIC-16 Package: Space-saving surface-mount design suitable for high-density PCB layouts.
  • Precision Resistance: Each resistor has a value of 10kΩ with a tolerance of ±2%, ensuring consistent performance.
  • Low Temperature Coefficient: ±100ppm/°C, maintaining stability across a wide temperature range.
  • AEC-Q200 Qualified: Meets automotive industry standards for high reliability.
