HMC522LC4TR – High-Linearity GaAs MMIC Mixer

Description

Technical Specifications:

• Mixer Type: Passive Double-Balanced Mixer
• RF Frequency Range: 7 GHz – 14 GHz
• LO Frequency Range: 7 GHz – 14 GHz
• IF Frequency Range: DC – 4 GHz
• Conversion Loss: 8 dB (typical)
• LO to RF Isolation: 35 dB (typical)
• LO to IF Isolation: 25 dB (typical)
• Input IP3 (Linearity): High-performance for minimal signal distortion
• Supply Voltage: No external DC bias required
• Package Type: 4×4 mm leadless ceramic (LC4)
• Operating Temperature: -40°C to +85°C
• Applications: Wireless infrastructure, radar, test instrumentation, satellite communication.

Product Features:

• Wide Frequency Range: Supports RF and LO frequencies from 7 GHz to 14 GHz.
• High Linearity: Offers excellent IP3 performance for superior signal integrity.
• Low Conversion Loss: Provides 8 dB typical conversion loss, improving efficiency.
• High Isolation: LO to RF and LO to IF isolation ensures minimal signal leakage.
• Integrated Balun: On-chip balun for optimized performance and ease of integration.
• Compact and Robust Package: 4x4 mm leadless ceramic surface-mount package (LC4) for space-saving designs.
