DK702 – High-Voltage Switch Mode Power Supply (SMPS) Controller

Description

Technical Specifications:

• Input Voltage Range: 85V – 265V AC
• Switching Frequency: 65kHz (Typical)
• Output Power: Up to 5W (depending on circuit design)
• Standby Power Consumption: <0.3W
• Efficiency: High power conversion efficiency
• Protection Features: Overload, short-circuit, and thermal protection
• Package Type: DIP-8
• Operating Temperature Range: -40°C to +105°C
• Applications: LED drivers, compact power adapters, household appliances, offline switch-mode power supplies.

Product Features:

• Wide Input Voltage Range: Supports direct operation from 85V - 265V AC mains.
• Integrated High-Voltage Startup Circuit: Reduces external components for a simpler design.
• Low Standby Power Consumption: Ensures energy-efficient operation in power-saving applications.
• Overload and Short-Circuit Protection: Prevents damage to circuits in case of faults.
• Thermal Shutdown Protection: Enhances safety by preventing overheating.
• Optimized for Low-Power Applications: Suitable for up to 5W power output.
• Compact DIP-8 Package: Space-saving design for PCB integration.
