Description

Technical Specifications:

• Microcontroller Core: 8051-based
• Flash Memory: 64KB
• RAM: 1KB
• ADC: 12-bit, up to 1MSPS (Million Samples Per Second)
• DAC: 12-bit
• Operating Voltage Range: 3.0V to 5.5V
• Communication Interfaces: I²C, SPI, UART
• Timers and Counters: Enhanced features for accurate timing and control
• Operating Temperature Range: -40°C to +85°C
• Package Type: 44-lead LQFP
• Power Consumption: Low power, energy-efficient design
• Applications: Ideal for industrial automation, embedded control systems, automotive electronics, and medical instrumentation.

Product Features:

• High-Performance 8051 Core: Built around the classic 8051 microcontroller architecture, offering high efficiency and compatibility with existing 8051 codebases.
• Integrated Analog Peripherals: Includes a 12-bit ADC and DAC, reducing the need for external analog components and simplifying system design.
• Wide Operating Voltage Range: Supports a wide input voltage range from 3.0V to 5.5V, offering flexibility in different system designs.
• Low Power Consumption: Designed for low power operation, ideal for battery-powered or energy-sensitive applications.
• 12-Bit ADC and DAC: The 12-bit resolution of both the ADC and DAC provides high precision for accurate signal processing and control.
• On-Chip Flash Memory: Includes 64KB of on-chip flash memory for program storage, with 1KB of RAM for data storage.
• Flexible Communication Interfaces: Supports I²C, SPI, and UART communication interfaces for easy integration with other devices and peripherals.
• Integrated Voltage Reference: Includes an integrated voltage reference for the ADC and DAC, ensuring precise measurements.
• Enhanced Timers and Counters: Equipped with enhanced timers and counters for precise timing and event control in various applications.
• Temperature Range: Operating temperature range of -40°C to +85°C, suitable for industrial and automotive environments.
• Package Type: Available in a 44-lead LQFP package for ease of integration in complex system designs.
