Description

Technical Specifications:

• Channels: 2 (Dual-channel)
• Filter Bandwidth: Adjustable from 1 MHz to 30 MHz
• Gain Range: 0 dB to 70 dB (VGA)
• Noise Figure: 9 dB typical
• Distortion (HD3): -50 dBc at 10 MHz
• Supply Voltage: +3.3V single supply
• Interface: SPI-compatible digital control
• Package Type: 40-lead LFCSP (6 mm x 6 mm)
• Operating Temperature Range: -40°C to +85°C

Product Features:

• Dual Programmable Filters: Independent low-pass filters with adjustable bandwidth from 1 MHz to 30 MHz.
• Integrated VGA: Variable gain amplifiers with a gain range of 0 dB to 70 dB for precise signal amplification.
• Wide Frequency Range: Supports high-frequency signals up to 30 MHz.
• Low Noise and Distortion: Ensures high signal integrity with excellent dynamic range.
• Flexible Control Interface: SPI-compatible digital interface for programmable settings.
• Compact Package: Available in a 40-lead LFCSP (Lead Frame Chip Scale Package).
• Applications: Ideal for wireless communication systems, software-defined radios (SDRs), and instrumentation.
