ADL5606ACPZ-R7 – High-Performance, Low-Noise RF Amplifier

The ADL5606ACPZ-R7 is a high-performance, low-noise RF amplifier designed for a wide range of RF and communication applications. With its excellent linearity, high gain, and low noise figure, it is ideal for use in wireless communication, test equipment, and instrumentation.

Product Brochure

Description

Technical Specifications:

  • Noise Figure: 0.7 dB (typical)
  • Gain: 26 dB (typical) at 900 MHz
  • Frequency Range: 400 MHz to 2.7 GHz
  • Supply Voltage: 5 V ±10%
  • Supply Current: 32 mA (typical)
  • Output Power: +18 dBm (typical)
  • Package Type: 5 mm x 5 mm LFCSP (Lead Frame Chip Scale Package)
  • Operating Temperature Range: -40°C to +85°C

Product Features:

  • Low-Noise Amplifier (LNA): Offers an ultra-low noise figure (0.7 dB typical) for high-fidelity signal amplification.
  • High Gain: Provides a high gain of 26 dB (typical) at 900 MHz, ensuring optimal signal strength for weak RF signals.
  • Wide Frequency Range: Operates from 400 MHz to 2.7 GHz, making it versatile for various RF communication bands.
  • Excellent Linearity: Maintains high linearity with minimal distortion, even under high input power levels.
  • Low Power Consumption: Operates with a low supply current of 32 mA, ensuring energy-efficient designs.
  • High Output Power: Supports a high output power of +18 dBm (typical) for strong and reliable signal transmission.
  • Single-Supply Operation: Can be powered by a single 5 V supply, simplifying circuit design.
  • Compact Package: Available in a 5 mm x 5 mm LFCSP package, suitable for space-constrained applications.
  • Applications: Ideal for wireless communication systems, test and measurement equipment, radar, and instrumentation.
